HY-YF550

Waterproof Beam Computer Moving Head Light (550/470/440/380/350)

Voltage: AC90V-240V 50-60Hz
Rated power: 500W
Light source: original and genuine OSRAM 470W or PHILIPS
Ballast: original OSRAM electronic ballast
Color temperature; 8000K
Color system: color disc: 13+1+multicolor rainbow effect+atomization function 6. Pattern system: pattern disc: 13 fixed pattern+1 white light 7. Focusing system: electronic focusing
Atomization; With atomization function and soft light effect
Stroboscopic; Dual motor independent stroboscopic effect, 0.5-20 times/second, adjustable speed
Motor: encoder three-phase motor is used for XY axis to ensure high stability of Light speed and positioning angle
Dimming curve: 0% - 100% linear dimming, smooth without flicker
Beam angle: 1.8 °
Channel: 16 channels
Lens diameter: 165mm
Waterproof grade: Ip65
Control mode 1: DMX 512, self-propelLED, master-slave self-propelLED, RDM function, can use large controller to control remote setting of address code
Control mode 2: DMX 512 signal wireless control transceiver can be built in, which makes the use of complex sites more convenient (needs to be customized by customers)
Prism system: 16 prisms and (8+16+24) prisms, single prisms and double prisms can be rotated (prisms can be configured according to customer requirements).
Display screen: LCD full-color LCD screen, suitable for different installation positions, can rotate 180 °
Horizontal and vertical: adopt high-precision three-phase magnetic coding motor, accurate positioning, smooth operation, and automatic correction and positioning
Horizontal: 540 ° rotation, resolution 8/16Bit, with fine adjustment
Vertical: 270 ° rotation, resolution 8/16Bit, with fine adjustment '.
Heat dissipation system: adopt the physical fan heat method, use the air convection system method and CFD software to analyze and calculate the heat flow of the Lights, quickly solve the internal heat of the body, extend the light decay time of the light source, ensure the service life of the bulb, and design a low-noise heat dissipation system with excellent fan drive performance and extremely low noise.
Installation method: upside down/side hung/flat
Light body size: 45 * 31 * 69cm
Net weight: 23 kg
